Tube PA calibré Polyamide

High precision calibrated polyamide tube.

Mono layer design in flexible polyamide, translucent or colored. Smooth inner and outer surfaces.

Applications

  •  Pneumatic controls
    Transfer of fluids and liquids under pressure: chemical products, fuel and lubricants, lacquers and solvents (please consult us)

Sectors of activity

  •  Used for automatic functions on all types of machines: concerns numerous industries using assembly machines, packaging lines…
    Laboratories

Advantages

In addition to being very light, the Tube PA provides excellent mechanical resistance to impact, fatigue, pulsing, flexing, abrasion and cutting. Its robustness gives it excellent performance under vacuum.
An active calibration process ensures its excellent dimensional accuracy.
Tube PA is made of polyamide 12. The characteristics of this material ensure good general chemical resistance and excellent impermeability to gases. Its low friction factor is provided by a very smooth texture of the inner and outer surfaces.
Varied colours help to identify the different networks easily. Packaging in a cardboard cassette facilitates storage.

Accords

Shut off connectors. P.C.L. type connectors.

Chemical resistance

Voir tableau pages 104 à 107 colonne F.

Markings

TUBE PA CALIBRE Ø int x Ø ext [N° lot]
