Spire Acier

Flexible transparent hose with metallic spiral.

With soft transparent PVC wall and galvanized steel spiral.

Applications

  •  Sewage
  • Suction and delivery of slurry
  • Transfer of chemical products, food products, liquids, powders and dust.

Sectors of activity

  •  Industry
  • Building

Advantages

Manufactured from high quality soft PVC with a galvanized steel spiral, Spire Acier is highly resistant to vacuum and crushing. The transparent wall is UV resistant and allows easy visual control of the fluid and identification of blockages. The smooth inner wall reduces flow losses and enables easy cleaning. Spire Acier is suitable for food contact applications up to 40°C. Alcohol beverages up to 50% alcohol content can also be conveyed up to 40°C.

Accords

Guillemin or Storz symmetrical connectors, cam or universal joint connectors – Fixing with singlethread or spiral collars.
Crimping band collars are not recommended as they do not ensure perfect leak-proof connection and increase the risk of the spiral being crushed or breaking.

Chemical resistance

See table pages 104 to 107 column A.

Warning

Spiral hoses in general have an elongation under pressure that can be important when temperature is above 40°C. This has to be considered before installation. We remain at your disposal for any question on this issue.

Markings

SPIRE ACIER ø int (EU) N° 10/2011 Sim A,B,C,D1 [N° lot]
